SolarEdge & SolarEdge optimiser P401-I-5RM4MRM

SolarEdge P401-I power optimisers for solar panels up to 420 Wp when used with third-party inverters

SolarEdge power optimisers enable you to get the maximum output from any PV system. The P401 optimiser is ideal for modules up to 420 Wp and is also suitable for third-party inverters.

When using optimisers, compatibility with the respective Inverters must be checked and the individual technical requirements met.

Product benefits

• Maximum performance at module level
• Not the entire string is affected by shading
• Continuous MPP tracking
• Module-based monitoring possible
• Higher output in shaded conditions and with different orientations
• Modules of different power classes can be combined without losses

Product features SolarEdge P401-I-5RM4MRM optimiser

• Max. rated input power: 420 W
• 12.5 A short-circuit current
• MPPT operating range 8–60 V
• Min. 4 optimisers per string with third-party inverters – the relevant design conditions must be taken into account
• Easy installation thanks to MC4 connection
• Input cable: 0.16 m
• Output cable: 1.2 m
• SafeDC function automatically reduces the voltage to 1 volt per module in the event of a fault
• Easy mounting on the mounting system using a hammer-head screw
• Compatible with all SolarEdge inverters

Power losses across an entire string due to shading or varying orientations are a thing of the past with SolarEdge power optimisers. Thanks to module-level MPP tracking, each module is controlled individually, enabling the string to deliver the maximum available power. Simple installation and maximum yield are easily achieved with the P401-I optimisers.
