Pylontech ReefMagic PRO Battery Module
| Gyártói cikkszám: | RMB70100-Pro |
|---|---|
| Cikkszám: | 16418 |
| Net capacity: | 7,5 kWh |
| Battery type: | High volt lithium-iron-phosphate |
| Cycles: | 8 000 |
| Solar battery type: | High voltage battery |
- Új
Pylontech ReefMagic PRO 7.5 kWh battery module for flexible battery storage
The Pylontech ReefMagic PRO RMB70100-Pro battery module is part of the ReefMagic modular high-voltage storage system, designed for both residential and commercial applications. Each module offers a capacity of 7.5 kWh, a nominal voltage of 73.6 V and a capacity of 102 Ah. The modular, stackable design allows for easy installation without complicated cable connections and enables the capacity to be gradually adapted to the requirements of a specific project. The system can be configured with up to 10 battery modules to achieve a total capacity of up to 75 kWh, whilst parallel connection of up to 6 groups is also supported. ReefMagic is also designed for outdoor installations and demanding conditions, offering a long design life of 15 years and more than 8,000 cycles.
Product benefits
- Modular and stackable design
- Quick and easy plug-and-play installation
- Option to create a battery system with a capacity of up to 75 kWh
- Parallel connection of up to 6 battery groups
- Suitable for outdoor installation
- Resistance to salt air
- Self-heating function
- Design life of 15 years
- More than 8,000 charging cycles
- Real-time online monitoring
Product features
- Module capacity: 7.5 kWh
- Module rated voltage: 73.6 V
- Battery capacity: 102 Ah
- Depth of discharge (DoD): 95%
- Charging and discharging current: 50 A
- Communication: Modbus RTU, CAN
- Protection rating: IP65
- Operating temperature: -20 to 55 °C
- Integrated aerosol fire suppression system
- Design life at 25 °C: 15 years
- Service life: more than 8,000 cycles
- Dimensions: 770 x 380 x 170 mm
- Weight: 57 kg
Manufacturer: Pylontech
Pylontech was founded in 2009 and specialises in the development and manufacture of battery systems for energy storage. It focuses on residential, commercial and industrial solutions and is one of the manufacturers that develops and manufactures key system components in-house, including battery modules, BMS and system integration. Thanks to its in-house research and development, Pylontech is able to offer comprehensive solutions with an emphasis on safety, reliability, long service life and easy capacity expansion. The company’s products are used in a wide range of applications, from domestic battery storage systems to large-scale commercial and industrial systems.
